HB PRO STACKABLE LITHIUM BATTERY
HB PRO 51.2V 200Ah is a modular stackable LiFePO4 energy storage battery designed for residential and small commercial ESS deployments that require scalable capacity and long-term operational reliability. Built with Grade-A prismatic LiFePO4 cells, it delivers excellent thermal stability, consistent discharge performance, and a lifespan of over 6000 cycles at 80% DOD. The system integrates an intelligent BMS that provides real-time cell balancing and full protection against overcharge, over-discharge, overcurrent, and temperature-related risks. With CAN and RS485 communication, the HB PRO 51.2V 200Ah supports seamless protocol matching with mainstream hybrid inverters such as Deye, Growatt, Victron, SMA, GoodWe, SOFAR, and Voltronic.
HB PRO STACKABLE LITHIUM BATTERY
Main Features
- Modular stack design; 10.24kWh per module, expandable to 40kWh+
- Grade-A LiFePO4 cells, lifespan >6000 cycles @ 80% DOD
- 200Ah high discharge capacity for home and small commercial loads
- Smart BMS with CAN / RS485 for inverter protocol compatibility
- Supports: Deye / Growatt / GoodWe / SOFAR / Victron / SMA / Voltronic
- >6000 cycles for long-term daily cycling applications
- Real-time BMS monitoring with cell balancing and fault protection
- Automatically cut off after 30days, no charge, and discharge to ensure security, and also can cut off output by manual operation.
- Quick installation, easy maintenance, suitable for distributor inventory
- 5-year warranty,10+years life time, LiFePO4 battery, more stable and safe.
- 10.24kWh per module, scalable architecture for flexible ESS sizing
- CAN / RS485 communication ensures smooth inverter integration
- Installer-friendly stack assembly reduces labor time and after-sales cost
HB PRO STACKABLE LITHIUM BATTERY
Main Features
- Modular stack design; 10.24kWh per module, expandable to 40kWh+
- Grade-A LiFePO4 cells, lifespan >6000 cycles @ 80% DOD
- 200Ah high discharge capacity for home and small commercial loads
- Smart BMS with CAN / RS485 for inverter protocol compatibility
- Supports: Deye / Growatt / GoodWe / SOFAR / Victron / SMA / Voltronic
- >6000 cycles for long-term daily cycling applications
- Real-time BMS monitoring with cell balancing and fault protection
- Automatically cut off after 30days, no charge, and discharge to ensure security, and also can cut off output by manual operation.
- Quick installation, easy maintenance, suitable for distributor inventory
- 5-year warranty,10+years life time, LiFePO4 battery, more stable and safe.
- 10.24kWh per module, scalable architecture for flexible ESS sizing
- CAN / RS485 communication ensures smooth inverter integration
- Installer-friendly stack assembly reduces labor time and after-sales cost
This HB PRO 51.2V 200Ah is wildly in using
Residential solar + battery hybrid systems (self-consumption + backup)
Households in regions with frequent power outages or unstable grids
Small commercial facilities requiring backup for refrigeration, POS, gates, lighting
Telecom relay stations, off-grid communication nodes, tower sites
Rural, agricultural, island, and remote distributed power systems
The Technical Parameter of HB PRO STACKABLE LITHIUM BATTERY
The HB PRO series provides stable daily cycling performance for solar energy storage, peak-shaving, and backup power needs — supporting reliable, safe, and long-term clean energy usage.Â
| MODEL | HH Pro 51.2V200Ah | HH Pro 51.2V300Ah |
|---|---|---|
| Basic | ||
| Battery Type | LiFePO4 | LiFePO4 |
| Nominal Battery Voltage (Vdc) | 51.2V | 51.2V |
| Nominal Capacity (Ah, 25°C 0.2C) | 200Ah | 300Ah |
| Nominal Energy (Wh, 25°C 0.2C) | 10240Wh | 15360Wh |
| Float Charge Voltage (Vdc) | 56.0V | 56.0V |
| Operation Voltage Range (Vdc) | 40.0–58.4V | 40.0–58.4V |
| Current | ||
| Max. Continuous Charge Current (A) | 100A | 200A |
| Max. Continuous Discharge Current (A) | 200A | 200A |
| Max. Pulse Discharge Current (A) | 300A 1s | 300A 1s |
| Terminal | M8 | M8 |
| Storage & Safety | ||
| Storage Temperature | 0°C ~ 30°C | 0°C ~ 30°C |
| IP Degree | IP20 | IP20 |
| Storage Duration | 6 months at 25°C | 6 months at 25°C |
| Safety Standard | UN38.3, MSDS | UN38.3, MSDS |
| Display (Optional) | LCD | LCD |
| Communication Port (Optional) | CAN, RS485, WiFi | CAN, RS485, WiFi |
| Protection | ||
| Protection | Overcharge, Overdischarge, Overcurrent, Short-circuit, Overtemperature | |
| Ambient | ||
| Working Temperature | -10°C ~ +50°C | -10°C ~ +50°C |
| Humidity | 0–95% (no condensation) | 0–95% (no condensation) |
| Sea Level (m) | ≤1500 | ≤1500 |
| Dimension | ||
| Product Size (mm) | 720 × 450 × 250 | 800 × 450 × 250 |
| Package Size (mm) | 920 × 600 × 350 | 1005 × 550 × 350 |
| N.W (Kg) | 90 | 118 |
| G.W (Kg) | 106 | 134 |
