HA 25.6V & 51.2V Wall Mounted Lithium Batteries
The HA PRO MAX 51.2V 200Ah is a floor-standing LiFePO4 energy storage system designed for residential and small commercial backup power applications. Built with Grade-A prismatic LiFePO4 cells, it delivers stable performance, excellent thermal safety, and over 6000 cycles at 80% DOD. The system features an integrated intelligent BMS that ensures cell balancing, thermal management, and multi-stage protection. With CAN / RS485 communication, it is compatible with mainstream inverter platforms such as Deye, Growatt, Victron, SMA, GoodWe, SOFAR, LuxPower, and Voltronic.
HA 25.6V100AH/51.2V50AH
Main Features
- 25.6V,51.2V LiFePO4 pack.Wall mounted design
- Space-saving floor-standing all-in-one design
- 6000+ cycle durability for long-term operation
- Max discharge current up to 200A, suitbale for inverter or solar system.
- Long life design, cells cycle time up to 5000 cycles, 5 years warranty, 10+ life design.
- With smart BMS system for all around protection.
- High density, small size and weight
- LCD display with communication port optional(CAN/RS485)
- All around protection and unattended operation
- High discharge output, suitable for inductive loads
- Smart BMS + CAN/RS485 inverter compatibility
- Fast installation, low maintenance cost
HA 25.6V100AH/51.2V50AH
Main Features
- 25.6V,51.2V LiFePO4 pack.Wall mounted design
- Space-saving floor-standing all-in-one design
- 6000+ cycle durability for long-term operation
- Max discharge current up to 200A, suitbale for inverter or solar system.
- Long life design, cells cycle time up to 5000 cycles, 5 years warranty, 10+ life design.
- With smart BMS system for all around protection.
- High density, small size and weight
- LCD display with communication port optional(CAN/RS485)
- All around protection and unattended operation
- High discharge output, suitable for inductive loads
- Smart BMS + CAN/RS485 inverter compatibility
- Fast installation, low maintenance cost
The Technical Parameter of HA 25.6V100AH/51.2V50AH
The vertical tower-style design provides a pre-assembled, plug-and-play energy storage unit, reducing installation labor and simplifying after-sales service — suitable for installers, distributors, and EPC integrators.
| MODEL | HA-25.6V100Ah | HA-51.2V50Ah |
|---|---|---|
| Case design | Wall mounted | Wall mounted |
| Battery Type | LiFePO4 | LiFePO4 |
| Normal Battery Voltage (Vdc) | 25.6V | 51.2V |
| Normal Capacity (Ah) | 100Ah | 50Ah |
| Normal Capacity (Wh) | 2560Wh | 2560Wh |
| Float Charge Voltage (Vdc) | 28.8V | 56.0V |
| Operation Voltage range (Vdc) | 20.0–29.2V | 40.0–58.4V |
| Max. Continuous Charge Current (A) | 50A | 25A |
| Max. Continuous Discharge Current (A) | 100A | 50A |
| Max. Pulse Discharge Current (A) | 150A 1Sec | 75A 1Sec |
| Terminal | M6 | M6 |
| Storage Temperature | 0℃ ~ 30℃ | 0℃ ~ 30℃ |
| IP degree | IP20 | IP20 |
| Storage duration | 6 Months at 25℃ | 6 Months at 25℃ |
| Safety standard | UN38.3, MSDS | UN38.3, MSDS |
| Display (Optional) | LCD | LCD |
| Communication Port (Optional) | CAN, RS485 | CAN, RS485 |
| PROTECTION | ||
| Protection | Overcharge, Overdischarge, Overcurrent, Short-circuit, Over-temperature | |
| AMBIENT | ||
| Working Temperature | −10℃ ~ +50℃ | −10℃ ~ +50℃ |
| Humidity | 0–95% (no condensation) | 0–95% (no condensation) |
| Sea Level (m) | ≤1500 | ≤1500 |
| DIMENSION | ||
| Products size (mm) | 460 × 300 × 139 | 460 × 300 × 139 |
| Package size (mm) | 540 × 440 × 219 | 540 × 440 × 219 |
| N.W (Kg) | 23.2 Kg | 23.2 Kg |
| G.W (Kg) | 25.0 Kg | 25.0 Kg |
